KOMODO-X™ 19.9MP Super 35mm Global Shutter CMOS

6144 × 3240

27.03mm x 14.26mm (Diagonal: 30.56mm)

16.5+ stops

Integrated locking RF mount with electronic communication

Supports /i PL lenses with RED RF to PL Adapters

Supports Canon EF Adapter with communication and other adapters based on the RF mount

Up to 560 MB/s using RED branded or other qualified CFexpress media cards¹

80 fps at 6K 17:9 (6144 x 3240)

96 fps at 5K 17:9 (5120 x 2700)

120 fps at 4K 17:9 (4096 x 2160)

240 fps at 2K 17:9 (2048 x 1080)

23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps, all resolutions

REDCODE HQ, MQ, LQ, and ELQ at 6K 17:9 (6144 x 3240) up to 80 fps

REDCODE HQ, MQ, LQ, and ELQ at 4K 17:9 (4096 x 2160) up to 120 fps

REDCODE HQ, MQ, LQ, and ELQ at 2K 17:9 (2048 x 1080) up to 240 fps

6K 17:9 (6144 x 3240), 2:1, 2.4:1, 16:9. 1:1, and Anamorphic 2x, 1.8x, 1.6x, 1.5x, 1.3x, 1.25x

5K 17:9 (5120 x 2700) and 16:9

4K 17:9 (4096 x 2160) and 16:9

2K 17:9 (2048 x 1080)

Dedicated recording in 4K (4096 x 2160) ProRes 4444 XQ up to 60 fps, ProRes 4444 up to 80 fps, and ProRes 422 HQ, ProRes 422, and ProRes 422 LT up to 120 fps

Aluminum Alloy

129.37 x 101.26 x 95.26 mm / 5.1 x 4 x 3.8 in (LxWxH, largest fixed dims.)

2.62lbs (without body cap and CFexpress card)

CFexpress Type B

Integrated V-Lock battery interface optimized for Micro V-Lock Batteries¹

11-17 V via 6-Pin DC-IN

0°C to 40°C (32°F to 104°F)

-20°C to 50°C (-4°F to 122°F)

0% to 85% non-condensing

Image Processing Pipeline 2 (IPP2)

Supports 33×33×33 3D LUTs

Supports import and adjustment of CDLs

Integrated dual channel digital mono microphones, uncompressed, 24-bit 48 kHz

Integrated dual channel (mic/line/+48V) input via 5-Pin 00B Audio Port, uncompressed, 24-bit 48 kHz

3.5mm stereo headphone port

Phase Detect and Contrast

Proprietary Top Accessory Port for Monitoring and Control

Integrated 2.9″ 1440×1440 touchscreen LCD with preview and camera control

Integrated 12G-SDI with 6G-SDI, 3G-SDI and 1.5G-SDI modes

12G-SDI: Up to 4096 x 2160 4:2:2 for 60p

6G-SDI: Up to 4096 x 2160 4:2:2 for 30p

3G-SDI: Up to 2048 x 1080 4:2:2 for 60p

1.5G-SDI: Up to 2048 x 1080 4:2:2 for 30p, 24p

SMPTE Timecode, HANC Metadata, 24-bit 48 kHz Audio

Tri-Level Genlock Input via 9-Pin EXT

LTC Timecode Input via 9-Pin EXT

RS232 CTRL (using RCP2) via 9-Pin EXT

Wi-Fi (2.4GHz/5GHz) for camera control, video preview, and media offloading

Ethernet via USB Type-C for camera control, video preview, and media offloading

MJPEG 1080p live stream accessible through Wi-Fi and USB Type-C.

PTP for frame level synchronization

R3D live broadcasting available with RED Connect License and 5Gbps Ethernet Adapter

Access full camera controls and live preview from iOS or Android devices.

Pro App: Operate one or multiple cameras over an IP connection to synchronize settings, manage media files locally or upload directly to FrameIO, develop custom looks with advanced CDL and LUT controls, and more. Ideal for control of multi-camera arrays, multi-cam shoots, and live events, all from one central location.

Standard app available from the Apple App Store and Google Play Store.

RED Control Pro available via Apple App store only and requires additional purchase.

RED Control works wirelessly or wired via USB Type-C
